Product Information
Introduction
The filling machine is fully automatic capsule filling and closing machine, suitable for dosing powder/granules in hard gelatin capsules.
It adopts intermittent motion and multi-position tamped dosing method to complete capsule orientation, separation, filling, closing and ejection etc. With different size parts the machine is suitable for size 00 to size 5 of empty capsules.
The production speed can be controlled by means of a frequency converter.
The machine is designed in accordance with GMP standards. All parts in contact with product are made of stainless steel. Advantage of the machine is advanced designing, novel structure, precise dosing, safe and reliable, high filling rate etc.
Features
- Filling structure is handled by modularity, as well as precious design, reliability and low wear and tear.
- With the function of auto detection when insufficient power, insufficient capsules (optional function) and malfunction happens. The machine can alarm and stop running automatically.
- Electric control system adopts PLC, and velocity modulation Electric parts choose famous trade mark, optional printing production data sheet.
- Production area and driving area are separated completely. All components are easy to dismantle due to special design. The material used meets pharmaceutical industrial requirements.
- New model structure, twelve work-position, whole close and intermittent turntable, upper and lower module’s one-way movement is very safety, close structure ensure the product avoiding oil pollution completely meets GMP stipulation.
- Adopt bore filling dosage.
- Transmission position: adopt high precision graduation structure.
Technical data
| Model | 800A | 1200A | |
| Max output(Capsules/min) | 800 | 1200 | |
| No. of segment bores | 7 | 9 | |
| Suitable capsule size | 00#~5# | 00#~5# | |
| Filling precision | ±3% | ±3% | |
| Noise | ≤70dB | ≤70dB | |
| Total power | 5Kw | 5Kw | |
| Dimensions (L*w*H) | 800*970*1870mm | 800*970*1870mm | |
| Net weight | 850kg | 850kg |
